• Japan Quality

• Tested 500,000 cycles

• Maximum Door Width: 900mm

• Maximum Door Weight: ≤45kg.

• Standard Application: Without hold open

• High strength pressure cast aluminum housing.

• Full rack and pinion mechanism.

• Closing and latching speed adjustable independently.

• Full Hydraulic Control

Controls the door through the entire opening and closing cycles by providing adjustable backcheck upon opening and adjustable general and latch speed through closing cycle.

• Optional adjustable backcheck

A backcheck feature set and adjusted by and independent valve. When introduced the backcheck stalls the opening of the door around 70 degress. When doors are violently opened by pedestrians or wind, the backcheck feature reduces the likelihood of damage should contact be made with an adjacent wall or obstacle.

• Latching Power Adjustment

By changing the position of the frame arm on the foot bracket closing force at the latch can be increased or decreased. This can be achieved with the foot bracket in position.

• Periodic Maintenance

None required other than to check security of fixing on a regular basis.
